LIBRA

There are many applications and adaptions to explore:

libra-main-on2
Tap Image For Libra Details
Libra Adaptions
LIBRA CONTROLS
libra-details-trans

Libra – 3 Axis Stabilised
Remote Head

Compact and lightweight, the Libra is a highly flexible stabilised camera mount easily riggable into most scenarios.
Fast and simple to set up it is a highly adaptable camera platform.
It accomodates all common camera / lens combinations. 35mm, 16mm, TV, Hi Def. Vista – Beaumont, IMAX – MSM camera packages.

SPECS

libra-upright
Libra Mount upright Specification

Height: 61cm
Width: 51cm
Depth: 21cm
Weight: 27Kg (no isodamp) / 31Kg (with isodamp)

Fits standard Mitchell / Moy fitting e.g. three way leveler; bazooka.
Pan: 350 degrees
Tilt: 270 degrees
Max Pan & Tilt speeds: 300 degrees/sec
Roll: 30 degrees either side of horizion

Sealed for wet / harsh environments. Temp range: -20 degrees C to + 45 degrees C. For temps less than -10 please call as Libra has been re-greased/tested at lower temps but is not standard Max camera package:150lb

libra-suspended
Libra mount Suspended Specification

Height: 76cm
Width: 51cm
Depth: 21cm
Weight : 27Kg (no isodamp) / 31Kg (with isodamp)

Fits standard Mitchell / Moy fitting e.g. three way leveller; bazooka.
Pan : 350 degrees
Tilt : 270 drgrees
Max Pan & Tilt speeds: 300 degrees/sec. Roll : 30 degrees either side of horizion
Sealed for wet/harsh environments

Temp range: -20 degrees C to + 45 degrees C. For temps less than -10 please call as Libra has been re-greased/tested at lower temps but is not standard Max camera package:150lb

USAGE

TRACKING CARS

All axes stabilised gives the ability to track on rougher roads, off road, high speed and with longer lenses.

The Libra remote head is mechanically stressed for hard hitting applications and has sealed components for harsh environmental conditions.

WIRE RIGS

Longrange wireless kits are available for cable rigs, descenders or tracks.

The Libra’s lightweight design enables full camera packages in weight restrictive applications. Upright or suspended for track requirements.

Motion repeat facility can be combined with certain tracks.

BOATS

For boat to boat, sea plates and POVs the Libra stabilised remote head gives a steady horizon on the water.

It’s compact design enables it to be moved quickly on small vessels, or rigged in the desired position on larger boats.

The Libra can be made submersible on request.

CRANES

Compact and lightweight, the Libra mount is a robust remote head with digital control for precise framing.

Highly spec’ed and whip pan capability. Switch in an instant for the Pan gyro to aid crane back panning.

Tilt gyro helps eliminate crane wobble

UNUSUAL

If it moves, the Libra mount stabilisation gives so much more to your capabilities.

Temperature rated for extreme cold and desert heat, -30 to +45, the Libra is a flexible tool for demanding situations.

For small vehicles the wireless capability enables the operator to be away from the rig in a safe position.
